Oxide Porting

Oxide Porting

An in-depth understanding of the necessary changes that are done when you're willing to transfer your Oxide server to Carbon.

FeatureCarbonOxide
Dynamic Patching
With the sheer amount of roughly 800+ Oxide hooks and patches, Carbon only fires and executes them when plugins need them, keeping things fully vanilla otherwise. On Oxide, all of these hooks fire at all times regardless if there are loaded plugins needing them, adding overhead. Learn more.
✅ Present
🚫 Absent
Self Updating
Carbon automatically updates the edition it's running (production, staging, etc.) without requiring any additional work. For example, on Rust wipe day, all you have to do is ensure that your Rust server is validated and updated, then booting it, Carbon will automatically self-patch for that Rust version.
✅ Present
🚫 Absent
Remote Hook Updates
On server boot, Carbon is looking to download the most recent updates for Oxide and Community hooks without requiring a full Carbon update. If there are hook failure patches (which usually doesn't happen), look for announcements in our Discord server, then just reboot the server to get the hook updates.
✅ Present
🚫 Absent
Profiler
Carbon has a built in profiler designed to profile performance of anything you wanna track (Rust, Unity, System, plugins, modules, extensions, you name it). Learn more.
✅ Present
🚫 Absent
Harmony 2.0
For the longest time, Rust used the outdated Harmony 1.0 which meant that Oxide was also using that outdated version in plugins. Carbon has always ran Harmony 2.0, then only fairly recently Facepunch updated Rust's Harmony version to 2.0, by proxy on Oxide also.
✅ Present
✅ Present
Regular Updates
Since the birth of Carbon (27th of August 2022), we've consistently released updates addressing issues, compatibility, QoL and implemented great ideas the community has contributed to the project with. Learn more.
✅ Present
🚫 Absent
Regularly Maintained
Carbon and Oxide have at least one thing in common; making sure the framework functions when Rust releases updates.
✅ Present
✅ Present

Automatic

Carbon has a built-in process which detects an existent Oxide installation and upon clean Carbon install (patch unzipped in the server root directory), will appropriately move all extensions found in RustDedicated_Data/Managed previously used with Oxide, in Carbon's dedicated directory.

Carbon also copies all config, data, lang, user & group data files and migrates it all at launch of the server, after files have been validated with Steam, since they're still patched with Oxide.

TIP

Ensure you validate all server files before initially starting up the server with Carbon for a clean boot. If things don't update, delete steamapps directory from the root of the folder first.

Manual

To understand changes necessary for handling things manually, follow the following instructions.

Config Folder

The <root>/oxide/config folder becomes <root>/carbon/configs. This is because early in the development of Carbon, we've named it that way since it makes more sense.

Extensions

The Oxide extensions, which in Oxide (for some reason) you place then in the brain folder of your Rust server, aka RustDedicated_Data/Managed, in Carbon it goes in its own dedicated directory, namely <root>/carbon/extensions.

If you need help to identify what an Oxide extension looks like in your files, any file with Oxide.Ext.*.dll format would be found in the Managed folder of an Oxide server.

Oxide (o.*) Commands

They don't work, this is Carbon. It might be difficult to get used to it, but all our commands are prefixed with c.*. Although you may create aliases which reflect commands.

Look for alias in the Commands page. Read more here.

Successful Transfer

There's a requirement where you must delete all Oxide.*.dll from your <root>/RustDedicated_Data/Managed folder, as well as verifying and re-updating your Rust server so files like Assembly-CSharp.dll get redownloaded, since Oxide processes them.

Take all extensions out of your <root>/RustDedicated_Data/Managed directory, and putting them in the respective Carbon extensions folder, removing Managed folder altogether, then performing an update & validation with steamcmd. This ensures that your server is cleansed and vanilla.
